New 2024 Kawasaki KFX 90

Engine

• RELIABLE & ACCESSIBLE: The KFX®90 ATV lets riders ages 10 and older take on tougher tracks. An 89.9cc four-stroke engine equipped with an electric start for simple and reliable starting produces smooth and predictable power. Parental controls include a keyed ignition to help address unsupervised use, as well as speed controls with a throttle-limiting screw to restrict throttle movement, and a collar in the automatic Continuously Variable Transmission (CVT) that can be removed to increase speed as the rider gains experience, allowing the KFX®90 to grow with the rider.

Four wheel fun starts with KFX®. Get the kids outdoors and ready to ride on the KFX®90 ATV line with proportionate power and size for riders ages 10 and older. KFX90 ATVs let kids take on more challenging tracks and bigger adventures with an 89.9cc engine and sporty suspension.

PERFORMANCE SPECIFICATIONS

Attribute	Specification
Engine	Air-cooled, 4-stroke, single-cylinder, SOHC, 2 valves
Displacement	90 cc
Bore x Stroke	47.0 x 51.8 mm
Compression Ratio	10.0:1
Maximum Power	4.8 kW {6.5 PS} / 7,500 rpm
Maximum Torque	6.6 Nm / 5,500 rpm
Fuel System	Carburetor (Keihin PTE16)
Ignition	CDI (Capacitor Discharge Ignition)
Starting System	Electric with back-up kick-starter
Transmission	Automatic CVT with centrifugal clutch
Final Drive	Chain, 2WD
Towing Capacity	N/A (not rated for towing)
Age Recommendation	10 years and older

SPEED & PERFORMANCE PROFILE

Parent-Adjustable Speed Control for Progressive Skill Development:

The KFX 90 is designed with progressive skill development in mind. Parental controls include a keyed ignition to help address unsupervised use, as well as speed controls with a throttle-limiting screw to restrict throttle movement, and a collar in the automatic Continuously Variable Transmission (CVT) that can be removed to increase speed as the rider gains experience, allowing the KFX®90 to grow with the rider .

This two-stage speed adjustment system provides:

• Stage 1 (Beginner): Throttle-limiting screw engaged, CVT collar in place – lower, safer speed range suitable for first-time riders
• Stage 2 (Experienced): Speed controls fully opened as rider demonstrates capability – increased performance for more confident young riders

Reliable 90cc Engine:

The KFX 90 is powered by an 89.9cc air-cooled, 4-stroke single-cylinder engine that produces smooth and predictable power for young, developing riders . Engine highlights include:

• Electric start with keyed ignition for simple, reliable starting
• Back-up kick-starter ensures the fun doesn’t stop if the battery runs low
• SOHC design with 2 valves for efficient, reliable operation
• Carbureted fuel system (Keihin PTE16) for simple maintenance
• Maximum power of 6.5 PS at 7,500 rpm

Automatic CVT Transmission:

The Continuously Variable Transmission (CVT) with centrifugal clutch provides seamless, automatic operation—no shifting required . Young riders can focus on the basics of steering, throttle control, and braking without the complexity of manual gear changes.

Automatic Clutch:
The automatic centrifugal clutch engages smoothly as engine speed increases, making it easy for young riders to get moving without stalling.

Protection

• GET A GRIP: Full coverage floorboards with slip-resistant footing contribute to increased grip and helps young riders control their ATV when riding while in a standing position. Effective mud protection keeps the engine running at a cooler temperature and keeps dirt and debris from building up near the engine.

Styling

• RIDE WITH SWAGGER: Front LED accent lights, and LED taillights add to the already race-inspired bodywork. Additionally a tall design of the front fenders conveys a strong sporty off-road performance look.

Suspension

• SMOOTH OUT YOUR RIDE: Independent A-arms in the front and swingarm rear suspension soak up bumps for a smooth ride and contribute to sporty handling.
